Glass Bending and Tempering System
Yuntong Z Series
Yuntong- Thickness
- 5-19
- Glass type
- Bent
- Factory-direct pricing
- Shipping, installation and commissioning quoted together
- No buyer premium
Talk directly with a glass machinery specialist.
Compare
For medium and large architectural bent and tempered glass, with a maximum product size of 3300mm x 20000mm.
- Radius adjustment and the whole production process are fully computerized
- All motion parts are surface hardened; system designed for a 25 year working life
- Bent and tempered output can be further laminated or made into insulating glass
Key Specifications
| Minimum glass size (mm) | 500 x 400 |
|---|---|
| Glass thickness range (mm) | 5-19 |
| Sizes in this series | 9 |
Figures as published by the manufacturer; not yet independently verified. (Yuntong catalog_2023EN.pdf, 7)
Models in this series
| Model | Max glass size (mm) | Min glass size (mm) | Radius min | Radius max | Glass thickness (mm) |
|---|---|---|---|---|---|
| WG1830Z | A1800 x H3000 | 500 x 400 | 900 mm | 45 m | 5-19 |
| WG2130Z | A2100 x H3000 | 500 x 400 | 1000 mm | 45 m | 5-19 |
| WG2430Z | A2400 x H3000 | 600 x 400 | 1000 mm | 60 m | 6-19 |
| WG2436Z | A2400 x H3600 | 600 x 400 | 1000 mm | 60 m | 6-19 |
| WG2442Z | A2400 x H4200 | 600 x 400 | 1000 mm | 60 m | 6-19 |
| WG3030Z | A3000 x H3000 | 800 x 500 | 1350 mm | 60 m | 6-19 |
| WG3036Z | A3000 x H3600 | 800 x 500 | 1350 mm | 60 m | 6-19 |
| WG3042Z | A3000 x H4200 | 800 x 500 | 1500 mm | 60 m | 6-19 |
| WG3050Z | A3000 x H5000 | 800 x 500 | 1800 mm | 60 m | 6-19 |
Main technical data of WG-Z series. Data is for sales reference and is not a contractual obligation. Jumbo bender installed: A3.5m x L20m.
Where it sits in the line
The stations before and after this machine on a glass processing line.
Glass Tempering Furnaces
Z Series
After
Similar machines
Manufacturer
Yuntong has concentrated on glass processing technology and machinery for over 40 years, and built China's first horizontal tempering furnace in 1989. The company reports leading work in zonal heating control, quenching power saving and forced convection heating, and states it has delivered over 700 tempering lines worldwide for architectural, appliance, automotive, furniture and PV glass.
