Continuous Glass Tempering Furnace
Jinglass Solar Glass Horizontal Continuous Tempering Furnace
Jinglass- Max sheet size
- 1400 x 2500
- Thickness
- 1.6-4
- Factory-direct pricing
- Shipping, installation and commissioning quoted together
- No buyer premium
Talk directly with a glass machinery specialist.
Compare
A continuous tempering line for photovoltaic glass.
- Handles ultra-thin PV glass from 1.6mm
- Exclusive high-pressure section with Y-sized air duct for even airflow
- Line width can be customized
Key Specifications
| Maximum glass size (mm) | 1400 x 2500 |
|---|---|
| Glass thickness range (mm) | 1.6-4 |
| Production rate | 2224 |
| Sizes in this series | 5 |
Figures as published by the manufacturer; not yet independently verified. (catalog 260320 compressed.pdf, catalog 31-32)
Models in this series
| Model | Thickness (mm) | Loading area (mm) | Max capacity (m2/h) | Max capacity (t/h) | Transformer capacity (kVA) |
|---|---|---|---|---|---|
| JGF-CF-5096-60M-2.5T | 1.6-4.0 | 1400 x 2500 | 2224 | 11.12 | 3150 x2 |
| JGF-CF-5096-54M-2.5T | 1.6-4.0 | 1400 x 2500 | 1992 | 9.96 | 3150 x2 |
| JGF-CF-5096-48M-2.5T | 1.6-4.0 | 1400 x 2500 | 1760 | 8.80 | 2500 x2 |
| JGF-CF-5096-42M-2.5T | 1.6-4.0 | 1400 x 2500 | 1528 | 7.64 | 3150 |
| JGF-CF-5096-36M-2.5T | 1.6-4.0 | 1400 x 2500 | 1296 | 6.48 | 2500 |
Above data is only for reference, the final data will be specified in the contract. Width can be customized.
Where it sits in the line
The stations before and after this machine on a glass processing line.
Glass Tempering Furnaces
Solar Glass Horizontal Continuous Tempering Furnace
After
Similar machines
Manufacturer
Jinglass Machinery, founded in 2003, specializes in intelligent tempering, providing digital solutions and tempering furnaces for glass processors worldwide. The company states it was first in the industry to implement an algorithm that automatically generates tempering parameters from glass layout and enables dynamic temperature control according to real-time glass position. Its ultra-thin tempering technology and temperature control process are reported in over 400 photovoltaic glass continuous tempering lines worldwide.
