Continuous Glass Tempering Furnace
Fuchong FC-LXPG Series
Fuchong- CE
- Max sheet size
- 1500 x 2200
- Thickness
- 2.5-10
- Factory-direct pricing
- Shipping, installation and commissioning quoted together
- No buyer premium
Talk directly with a glass machinery specialist.
Compare
A continuous line for photovoltaic and household appliance glass.
- Real continuous tempering with glass always moving forward, never backward
- Ascending temperature setting for even heating and reduced heat shock
- Production capacity several times that of a traditional radiation furnace
- Energy consumption 2.5 to 2.8 kWh per square meter
- Infrared temperature detecting device and UPS power
Key Specifications
| Maximum glass size (mm) | 1500 x 2200 |
|---|---|
| Glass thickness range (mm) | 2.5-10 |
| Production rate | 400 m2/h |
| Sizes in this series | 12 |
Figures as published by the manufacturer; not yet independently verified. (Fuchong Glass_Catalog2025.pdf, 09-10)
Models in this series
| Model | Max size (mm) | Thickness (mm) | Yield (3.2mm solar glass) | Energy consumption (kWh/m2) | Furnace length (m) |
|---|---|---|---|---|---|
| FC-LXPG1020-30 | 1000 x 2000 | 2.5-5 | 400 m2/h | 2.5-2.8 | 30 |
| FC-LXPG1020-36 | 1000 x 2000 | 2.5-5 | 450 m2/h | 2.5-2.8 | 36 |
| FC-LXPG1222-15 | 1200 x 2200 | 2.85-5 | 260 m2/h | 2.5-2.8 | 15 |
| FC-LXPG1222-20 | 1200 x 2200 | 2.85-5 | 350 m2/h | 2.5-2.8 | 20 |
| FC-LXPG1222-24 | 1200 x 2200 | 2.85-6 | 410 m2/h | 2.5-2.8 | 24 |
| FC-LXPG1222-30 | 1200 x 2200 | 2.85-8 | 500 m2/h | 2.5-2.8 | 30 |
| FC-LXPG1222-36 | 1200 x 2200 | 2.85-8 | 560 m2/h | 2.5-2.8 | 36 |
| FC-LXPG1222-48 | 1200 x 2200 | 2.85-8 | 700 m2/h | 2.5-2.8 | 48 |
| FC-LXPG1422-42 | 1400 x 2200 | 2.85-5 | 700 m2/h | 2.5-2.8 | 42 |
| FC-LXPG1422-48 | 1400 x 2200 | 2.85-6 | 800 m2/h | 2.5-2.8 | 48 |
| FC-LXPG1422-60 | 1400 x 2200 | 2.85-8 | 1000 m2/h | 2.5-2.8 | 60 |
| FC-LXPG1522-60 | 1500 x 2200 | 2.85-10 | 1030 m2/h | 2.5-2.8 | 60 |
The above types are the normal ones; Fuchong can design to special requirements. Yield figures assume 3.2mm solar glass.
Where it sits in the line
The stations before and after this machine on a glass processing line.
Glass Tempering Furnaces
FC-LXPG Series
After
Similar machines
Manufacturer
Luoyang Fuchong Machinery researches, designs, sells and installs glass deep processing equipment under the FULL-TIME brand. Its main products are flat tempering furnaces, fireproof glass tempering furnaces, double curvature tempering furnaces, continuous flat and bending tempering furnaces, and bending, unequal arc bending and special shaped bending tempering furnaces.
View the manufacturerFuchong FC-LXPG Series
