Straight-Line Edging Machine
Lattuada North America AL T Series
Lattuada North America- Founded 1978
- UL
- CSA
- Thickness
- 3-20
- Automation
- Automatic
- Glass type
- Flat edge
- Power
- 13
- Factory-direct pricing
- Shipping, installation and commissioning quoted together
- No buyer premium
Talk directly with a glass machinery specialist.
Compare
Peripheral straight-line edging machines for processing the pencil edge, OG or flat edge with arris, sharing the AL series' base structure and technology.
- Conveyor with support pads
- Automatic lubrication system
- Lattuada spindles, described as a unique solution for motion transmission
- Copper pipes for cooling the wheels and the internal of the spindle tank
- Electrical system with UL/CSA-compliant components and IE3 high-efficiency motors
- Digital ammeters with an automatic polishing-wheel wear detection system
Key Specifications
| Glass thickness range (mm) | 3-20 |
|---|---|
| Installed power (kW) | 13 |
| Machine footprint (m) | 6.285x1.450xH2.400 mm (247.4x57xH94.5") |
| Sizes in this series | 2 |
Figures as published by the manufacturer; not yet independently verified. (company-profile-en.pdf; glass-solutions-en.pdf, glass-solutions-en.pdf catalog p.15 (PDF p.17))
Models in this series
| Model | Speed | Min glass size | Workable glass thickness | Installed power (kW) | Dimensions | Max glass load (on conveyor) | Max glass load (total) |
|---|---|---|---|---|---|---|---|
| AL 4T | 0.5-4 m/min (20-157 in/min) | H60 mm (H2.4") | 3-20 mm (1/8-3/4") | 10 | 6.285x1.450xH2.400 mm (247.4x57xH94.5") | 400 Kg - 200 Kg/m (881 lbs - 11.2 lbs/") | 700 Kg (1,543 lbs) |
| AL 6T | 0.5-4 m/min (20-157 in/min) | H60 mm (H2.4") | 3-20 mm (1/8-3/4") | 12.5 | 6.285x1.450xH2.400 mm (247.4x57xH94.5") | 400 Kg - 200 Kg/m (881 lbs - 11.2 lbs/") | 700 Kg (1,543 lbs) |
Where it sits in the line
The stations before and after this machine on a glass processing line.
Glass Edging and Polishing Machines
AL T Series
Similar machines
Manufacturer
Lattuada North AmericaInformation supplied by manufacturerLattuada North America, Inc. is the US subsidiary of Adelio Lattuada S.r.l., an Italian manufacturer of flat-glass processing machinery founded in Carbonate (Como), Italy in 1978 by Adelio Lattuada. Lattuada North America opened its headquarters in Northwood, Ohio in 2017 to strengthen the spread of Lattuada machines and offer targeted services to the US market. The catalogs state the company's offering includes more than 40 models of straight-line edging machines, double-edgers (in several configurations) and straight-line bevelling machines, plus vertical glass washing machines, automatic corner grinding machines and horizontal drilling machines.
